| ELECTRICAL SPECIFICATION |
| Characteristic Impedance |
50 ± 1 Ω |
| Maximum Operating Frequency |
3000 MHz |
| Peak RF Voltage Rating |
1.39 kV |
| Peak Power Rating |
19.0 kW |
| Attenuation (at cable) |
1000MHz: 0.11dB/m, 2000MHz: 0.17dB/m |
| Connector Attenuation |
≤ 0.1dB |
| Average Power Rating |
1000MHz: 710W, 2000MHz: 480W |
| Intermodulation, typical (2x20W TX) |
800~1000MHz: -160dBc, 1600~2000MHz: -160dBc |
| Maximum Pulling Force |
500 N |
| Minimum Bending Radius |
Single Bending: 15mm, Repeated Bending: 30 mm |
| Waterproof Mechanical Characteristics Level |
IP68 |
| Return Loss (VSWR) |
With 7/16 male and female, N male and female connectors: 0~1000MHz: 28dB, 1000~2700MHz: 26dB With 7/16 male 90°, N male 90° connectors: 0~1000MHz: 26dB, 1000~2700MHz: 24dB |
