N-type Male Straight to QMA Male Straight for LMR-240 Cable of Length 1M
P/N : VSW250090-CA
- RF Cable Assembly
- N-Type Cable Assembly
- N-Type to QMA Cable Assembly
- LMR-240 Cable
- N Male to QMA Male R/A
Click Here To Download Datasheet
For Orders & Info
Description
| CONNECTOR SPECIFICATION | |
| RF Series 1 | N-type |
| Gender | Plug (Male) |
| Orientation1 (body) | Straight |
| Body Finish | Gold |
| Body Material | Brass |
| Contact Finish | Gold |
| Contact Material | Brass |
| RF Series 2 | QMA |
| Orientation 2 (body) | Right Angle |
| Gender 2 | Plug (Male) |
| Body Finish | Gold |
| Body Material | Brass |
| Contact Finish | Gold |
| Contact Material | Brass |
| Frequency | DC-6Ghz |
| Impedance | 50 Ω |
| VSWR | ≤1.2 |
| CABLE SPECIFICATION | |
| Cable Type | LMR240 |
| Cable Diameter | 6.10 mm |
| Frequency | 8 GHz |
| Impedance | 50Ω |
| Length | 1Meter |
| Temperature Rating | -40°C ~ +85°C |
