RF Variable Attenuator(2W DC-6GHz SMA Female To N Female)
P/N : VSW260053-ATT
- RF Variable Attenuator
- 50Ω
- 2WÂ
- SMA Female To N Female
- Max Frequency(GHz)Â – DC-6
Click Here to get Data Sheet
For Orders & Info
Description
| TECHNICAL & MECHANICAL SPECIFICATIONS | |
| Frequency(GHz) | DC-6 |
| Decay step | 0-90dB in 10dB steps |
| VSWR max | 1.40 |
| Insertion Loss(dB) | ≤1.0 |
| Accuracy(dB) | ±1.5(10~60dB)
±2.5 or 3.5%(70~90 dB) |
| Average power(W) | 2W |
| Peak power(W) | 200W (5μs pulse width, 2% duty cycle) |
| Impedance(Ω) | 50 |
| Connector | SMA (F, F) |
| Connector housing | Nickel-plated brass |
| Concealed conductor | Gold-plated beryllium bronze |
| Cavity | Aluminum housing, painted (royal blue) |
| Temperature range(℃) | 0℃~+54℃ |
| Dimensions(mm) | Ø48*108mm |
| Weight(g) | 280g |
