Power Amplifier (2W 1.1GHz to 1.7GHz)
P/N : VSW260016-AMP
- RF Amplifiers
- 50Ω
- SMA Female
- Max Frequency (GHz) – 1.1 to 1.7
Click Here to get Data Sheet
For Orders & Info
Description
| SPECIFICATION | ||
| Frequency | 1.1GHz to 1.7GHz | |
| Gain(dB) | Min | Max |
| 25 | 35 | |
| Input Power(W) | 2 | 2.5 |
| Gain flatness(dB) | 0.3 | 0.5 |
| Noise Figure | < 1.5 dB | |
| Input & Output Impedance | 50Ω | |
| Power supply | 5 Volts DC 3 Amps | |
| Environment | Outdoor, protected from rain | |
| RF Input & Output Connectors | SMA Female | |
