RF Fixed Attenuator (2W 5dB 500 KHZ ~ 6000 MHZ SMA Male to Female)
P/N : VSW250028-ATT
- RF Fixed Attenuator
- 50Ω
- SMA Male to Female
- 2WÂ
- Attenuation(dB) – 5dB
- Max Frequency – 500 KHZ ~ 6000 MHZ
Click Here to get Data Sheet
For Orders & Info
Description
| SPECIFICATION | |
| Type | RF Attenuator |
| Gender1 | Male |
| Connector 1 Series | SMA |
| Gender2 | Female |
| Connector 1 Series | SMA |
| Gender2 | Female |
| Body Finish | Passivated |
| Body Material | Stainless Steel |
| Contact Finish | Gold |
| Contact Material | Beryllium Copper |
| Impedance (Ohms) | 50 |
| Power Input | 2Watt |
| Attenuation | 5dB |
| Attenuation Accuracy | ±0.5dB |
| VSWR | <1.30:1 |
| Dielectric | PTFE |
| Max Frequency               | 500 to 6000MHz |
| Min. Temp. (Celsius) | -55°C |
| Max. Temp. (Celsius) | +125°C |
