Rotary Step Attenuator(5W DC-4GHz N Female to Female)
P/N : VSW260023-ATT
- RF Rotary Step Attenuator
- 50Ω
- N Male to Female
- 5WÂ
- Max Frequency(GHz)Â – DC-4
Click Here to get Data Sheet
For Orders & Info
Description
| TECHNICAL & MECHANICAL SPECIFICATIONS | |
| Frequency Range(GHz) | DC-4 |
| Attenuation Step Size | 0-90dB in 1dB steps |
| Max VSWR | 1.45 |
| Insertion Loss(dB) | ≤4.5 |
| Attenuation Accuracy(dB) | 0-10dB±0.5dB；
11-30dB±0.8dB； ±2.5%@≥30dB |
| Nominal Impedance | 50Ω |
| Average power | 5W |
| Connector type | N(F,F) |
